MONEL FLANGES

Name: MONEL FLANGES
Brand: MANIBHADRA METALS
Price: 2000 INR
Availability: InStock

Price 2000 INR/ Kilograms

Get a Price/Quote

MOQ : 5 Kilograms

MONEL FLANGES Specification

Product Form
Forged/Threaded/Socket Weld Flange

Heat Resistance
Yes

Tensile Strength
517 MPa min (Monel 400)

Recyclable
Yes

Width
Custom as per requirement

Material Composition %
Nickel 63-70%, Copper 28-34%

Chemical Composition
Nickel (63-70%), Copper (28-34%), with traces of Iron, Manganese, Silicon, Carbon, Sulfur

Temper
Annealed

Corrosion Resistant
Excellent resistance to seawater & acids

Hardness
65-85 HRB (Monel 400)

Coating Type
Uncoated / Custom available

Diameter
1/2 to 24 (DN15 to DN600)

Size
Custom sizes available

Product Name
Monel Flanges

Steel Type
N/A (Nickel-Copper Alloy)

Steel Product Type
Flanges

Grade
Monel 400, Monel K500

Thickness
As per specification

Shape
Round, Square, Custom

Steel Standard
ASTM B564 / ASME SB564

Surface
Polished/Shot blasted

Composition
Nickel-Copper Alloy

Application
Oil & Gas, Petrochemical, Marine, Chemical Processing, Power Plant, Flue Gas Desulfurization

Dimension (L*W*H)
Standard/As per drawing

Weight
Variable, depends on size & type

Color
Silver/Metallic

Material Grade
Monel 400, Monel K500

Finish Type
Smooth

Usage
Pipe connections, chemical processing, marine fittings

Manufacturing Process
Forged/Heat Treated

Magnetic Permeability
Low

Connection Type
Weld Neck, Slip On, Blind, Threaded

Temperature Range
-29C to 480C

Standards
ANSI, EN, DIN, JIS, BS, GOST

Machinability
Good

End Connection
Flat Face, Raised Face, Ring Type Joint (RTJ)

Pressure Rating
Class 150 to 2500

Density
8.80 g/cm3

Lead Time
2-6 weeks depending on size and quantity

MONEL FLANGES Trade Information

Minimum Order Quantity
5 Kilograms

Supply Ability
1000 Kilograms Per Month

Delivery Time
3 Days

MONEL FLANGES About

Capitalise on the unrivalled durability and corrosion resistance of our MONEL FLANGES, meticulously engineered for opulent performance and breathtaking longevity. Crafted from premium Nickel-Copper alloys (Monel 400, Monel K500), these sterling flanges guarantee adaptability for every pipe connection-whether Weld Neck, Slip On, Blind, or Threaded. Conforming to ANSI, DIN, EN, and more, and forged for strength, their polished or shot-blasted finish radiates brilliance. Buy online and personalise your order with tailored sizes and custom coatings, and experience seamless integration into marine, oil & gas, and chemical processing plants.

Application of MONEL FLANGES: Versatility in Demanding Environments

MONEL FLANGES excel in applications requiring exceptional resistance, such as oil & gas pipelines, chemical processing plants, power stations, and marine installations. Their rugged construction ensures secure pipe connections via welding, threading, or socket welding. Commonly used for high-pressure and corrosive environments, these flanges guarantee operational safety and minimal downtime. Select from round, square, or custom shapes to perfectly suit design specifications, enabling easy incorporation into new or retrofit plant projects for any industrial piping system.

Export Markets, Sale Pricing, and Efficient Delivery of MONEL FLANGES

Our MONEL FLANGES are exported to major international markets, valued for their sterling quality across petroleum, marine, and chemical industries. With competitive sale prices, we offer secure packaging options tailored for safe transportation worldwide. Samples are available upon request, ensuring full confidence in your purchase. Delivery times range from 2-6 weeks depending on order size and specifications, ensuring swift supply and smooth logistics for urgent or bulk requirements.

FAQ's of MONEL FLANGES:

Q: How do MONEL FLANGES enhance performance in harsh environments?

A: MONEL FLANGES offer exceptional resistance to corrosion, seawater, and acids, making them ideal for demanding oil & gas, marine, and chemical processing applications. Their robust construction supports reliable performance even at elevated temperatures up to 480C.

Q: What connection types and face finishes are available?

A: These flanges come in weld neck, slip on, blind, threaded, and socket weld types, with options for flat face, raised face, and ring type joint (RTJ) surfaces. Custom face finishes and shapes can also be provided as per specification.

Q: Where can I buy MONEL FLANGES online and can I personalise my order?

A: You can conveniently buy MONEL FLANGES online from our trusted website. Orders can be personalised by specifying size, grade, surface finish, and custom coatings to meet exact project requirements.

Q: What industries benefit most from MONEL FLANGES?

A: Industries such as oil & gas, petrochemical, marine engineering, power plants, and flue gas desulfurization benefit significantly due to the superior corrosion and heat resistance of MONEL alloys.

Q: What is the lead time for delivery and are samples available?

A: Delivery typically takes 2 to 6 weeks based on the order's size and complexity. Samples are available to help ensure the product's suitability for your specific application.
